7 Series Pneumatic Electric Four Wheel

3,200 lbs. - 4,000 lbs. Capacity

Our 7 Series 4 wheel counter balance forklift trucks continue the Doosan tradition of delivering simple, powerful performance, at the best possible value for our customers.

Download Brochure

Safety

Ease of Access Ensures Maximum Safety

  • Large step plate with an anti-slip pattern ensures firm footing even for large safety boots
  • Easy grip entry bar makes entering and exiting the machine safer
  • Large uncluttered floor plate with no trip hazards provide improved comfort and more leg room
  • Angled floor plate reduces strain on the ankles, and large pedals ensure maximum safety and ease of operation

Rear Grab Handle

Adds to safety, comfort and convenience when traveling in reverse.

Unlimited Ramp Hold

The Electro-magnetic Auto Parking Brake (EPB), prevents the forklift from rolling back if parked on slopes, allowing the operator to safely get out without braking.

Mast Lowering Interlock

If the operator keys off, or gets off the seat, the hydraulic lift and tilt locking system will limit the motion of the truck.

Mast Lowering Tilt Lock

Hydraulic locks prevent hydraulic lift when lowering and tilting.



Download Brochure
Safety

Convenience

Convenience

Ergonomic Interior Design

The steering column, full suspension comfort seat, armrest and even the optional headrest are all fully adjustable to accommodate any operators’ individual preferences.

Easy to Control

The all-new Finger-tip Controls: Optimal ergonomics giving optimal performance. These fast, precise and instinctive controllers make operating the new Doosan 7 Series effortless and efficient.

Panoramic Mirror

Provides the operator a clear view of the whole back & rear working area, improving work safety & efficiency

Turtle Mode

Reduce travel speed to a previously set parameter without affecting lift speed

Download Brochure

Maintenance

Extended maintenance intervals and advanced technology componentry reduce the overall cost of maintenance.

  • Easy to Access Controller & Motors Room
  • Wide Open Battery Cover
  • Tool-Less Side Cover with Air Ventilation
  • Easy Diagnostic & Fine-Tune
  • Curtis controller, reliable stable operation. IP65 rated.

Oil Cooled Disc Brakes  (ODB)

Virtually maintenance free, ODB is standard equipment for the 7 Series 4 wheel electric forklifts. The enclosed system eliminates outside contamination, thus can last 5 times as long as conventional brake shoes.

Download Brochure
Maintenance

Extended Value

Extended Value

Maximized Productivity in Warehouse Applications

Effective storage is the primary goal for many warehouse managers. Our 4 wheel models have steer axles that turn 86°, enabling the machines to maneuver with ease even in the tightest spaces.

Outdoor Operations

The Doosan 7 Series electric forklifts are waterproof and are safe for outdoor use. The sealed controllers are rated IP65 and the motors are rated IP43, with all related wiring & connectors being silicon-sealed.

Download Brochure

7 Series Pneumatic Electric Four Wheel

Our 7 Series 4 wheel counter balance forklift trucks continue the Doosan tradition of delivering simple, powerful performance, at the best possible value for our customers.

MODEL B16X-7B18X-7B20X-7
RATED CAPACITY (lb)3,2003,6004,000
STEER ANGLE (degrees)868686
VOLTAGE484848
TRAVEL SPEED (mph)10.610.610.6
MAX GRADEABLITY (% at 1.0 mph, Loaded)262526
